1, General Description:
This bed is designed for women's parturition and gynecological operation. It's raising, lowering and the up-down folding of the back section are all conducted electrically and controlled by buttons. It is characterized by versatility, easy operation, safety and reliability.
2, Specifications:
Dimensions of Table Top:
Overall Length...1900mm
Width...600mm
Table Top from Floor:
Max Height...990mm
Min Height...750mm
Adjustments of Section:
Back section raised from the horizontal...≥ 40°
Back section lowered from the horizontal...≥ 10°
Leg section lowered from the horizontal...≥ 90°
Safe Working Load...135kg
Supply: AC220± 10%, 50Hz± 1
Device safety sort: I B
3, Operation Instruction:
The ascending and descending movements, back section raised or lowered of the table top are all electrically operated. It has a moving controlling push button container attached. The controlling push button are all DOT buttons, when the necessary button is rushed, the corresponding motor will work, when the button is not pressed, all movements stop.
1)Connect with power supply.
2)Push the corresponding buttons, the parturition can carry out the action.
3) The motion idler wheel is installed in the pedestal of the operating table, it can be locked to the ground when trampling the side pedal, it can move around when tramping the other side pedal.
4) Leg section is ascended, forward move the hook must be locked. When the leg section is horizontal, it can be used.
5) Electric operating table mattresses are produced by the high-density sponge covered leatherette materials, with antistatic properties.
6) The Company will be able to provide circuit draws in accordance with user's needs.
