KL-5A obstetric bed is suitable for typical operations such as parturient delivery, prenatal examination, operative abortion and gynecological examination.
Features:
The main and auxiliary tables can be separated and also joined up. The auxiliary table is provided with truckles and braking device.
Various actions of main bed are adjusted by gear and of auxiliary bed are adjusted by ratchet.
With various complete accessories.
The bed body and bed surfac both adopt high 304 stainless steel.
KL-5A Standard Accessories:
A pair of arm resting frame, a pair of leg support frame.
Length): 1900± 50mm
Width): 600± 20mm
Maximum and minimum height of the platform): 750± 20mm, 950± 50mm
Ascending distance): 200± 50mm
Forward) ≥ 20°
Backward) ≥ 15°
Leftward) ≥ 15°
Rightward) ≥ 15°
Back board fold upward)≥ 50°
Head board fold upward)≥ 18°
Head board fold downward)≥ 90°
Leg board fold downward) ≥ 70°
Table rated load capacity): 135Kg
| Length | 1900± 50mm |
| Width | 600± 20mm |
| Maximum height of the platform | 750± 20mm |
| Minimum height of the platform | 950± 50mm |
| Ascending distance | 200± 50mm |
| Forward | ≥ 20° |
| Backward | ≥ 15° |
| Leftward | ≥ 15° |
| Rightward | ≥ 15° |
| Back board fold upward | ≥ 50° |
| Head board fold upward | ≥ 18° |
| Head board fold downward | ≥ 90° |
| Leg board fold downward | ≥ 70° |
| Table rated load capacity | 135Kg |
