1 ml/h 1-9999 ml 1-9999 ml Features:
Innovative door-free design for easy operation
Middle Detection and Ultrasound Detectors to double guarantee the correct IV set loading
Anti-bolus system to reduce significantly bolus after occlusion sudden release
Reminder alarm in case of forgetting to start the operation
High speed infusion up to 2000ml/h satisfies special clinical scenario
Optional drip sensor and fluid heater
Wireless data transmission with infusion supervision system
Technical parameters:
Mechanism | Peristaltic pump |
Operating Mode | Flow Rate Mode, Drop rate Mode (optional) |
Preset Volume | 1-9999 ml |
Accumulated Infusion Volume | 1-9999 ml |
Flow Rate Range | 1 - 600 ml/h for 600I Infusion Pump |
Increment | 1, 10, 100 (ml/h) |
Accuracy | ± 5% |
KVO Rate | 1 ml/h |
Bolus Rate | 600 ml/h |
Drop rate range | 1 - 400 drop/min with optional Drip Sensor |
Display Screen | 2.7 inch B/W LCD |
Alarm Type | Air Bubble Level: 1-3 levels adjustable, turn off |
Occlusion Alarm Pressure Range: 3 levels: 70kPa, 100kPa, 130kPa (±30kPa), Level Low as default |
Battery Type: Lithium polymmer battery
Life: Up to 2 hours continuous operation@25 ml/h flow rate with standard battery(1 hour for 600IB)
Up to 4 hours continuous operation@25 ml/h flow rate with optional battery(2 hours for 600IB)
Environment:
Temperature 5 - 40 ºC for operating, -20 - 50 ºC for storage
Air Pressure 86 - 106 kPa for operating, 50 - 106 kPa for storage
Humidity 20 % - 80 % for operating, 10 % - 95 % for storage
Others:
Classfication | Class II, Type CF |
Dimension (L*D*H) | 120*140*195mm |
Weight | 1.7kg |
Power supply | 100-240VAC, 50/60Hz |
Waterproof level | IP21 |
