Multi-Purpose Operating Table (model JT-2A)
You are here: Home » Products » Operation Room Product » Operation Table » Multi-Purpose Operating Table (model JT-2A)
Share to:

Multi-Purpose Operating Table (model JT-2A)

  • JT-2A
  • Operating Table
  • Single
  • Black
  • New
  • 930*690mm
  • Left >=18°, Right >=18°
  • Down >=90°
  • 1770*770* 940mm
  • everich
  • China
  • Stainless Steel
  • Diagnosis Room
  • Folded
  • Customized
  • 1960*480mm
  • Forward >= 25°, Backward >=20°
  • up >=85°, Down >=10°
  • 288kg
  • >=80mm
  • CE, ISO
  • 9402900000
THIS TABLE IS USED FOR OPERATION AND EXAMINE OF THORACO-ABDOMEN, ORTHOPAEDICS, E. N. T. Department, gynaccology and obstetrics and urological department. There is a shelf fixed under the table. Put the magazine on the shelf. Adjust the location to be shooted and then, the X-ray photography might begin. The surface of the table is all made of high-quality, erosion-resistant stainless materials and the mattress adjust new type of acidbase and sterilization-resistant materials. The bottom seat is movable and can be licked. Using the imported cylinder, the table has got the best position for clinical uses with its unique hydraulic and pneumatic technology and flexible convenient operation to improve the operation rate of a doctor.

Technical Data:
Length and width for tabletop: 1960*480mm
Max.&Min. Height for tabletop: 930*690mm
Max. degree for tabletop forward and backward tilting: forward ≥ 25°, backward ≥20°
Max. degree for tabletop left and right tilting: left ≥18°, right ≥18°
Max. degree for back rest adjustment: up ≥85°, down ≥10°
The range of leg rest adjustment: down ≥90°
The range of back rest adjustment: up ≥75°, down ≥10°
The range of head rest adjustment: up ≥45°, down ≥50°
Kidney bridge elevation: ≥80mm

Gross weight: 288kg
Measurement: 1770χ 770χ 940mm
