± Parameters:
Two Parameters: SPO2, Pulse Rate.
Waveforms:
No Waveform.
Features:
1. Small, light, easy for carrying and handling.
2. Brightness LED displays, easy to read, and the brightness can be adjusted.
3. Build-in rechargeable Ni/MH battery, longtime operating time.
4. Audio and visual alarm, and alarm limit can be set.
5. Automatic Power-off.
6. Battery capacity indicator.
H. S. Code: 90189090
Net Weight: 0.3kg
Gross Weight: 1.0kg
Package Size: 210*160*70mm
Color
Yellow or Blue can be selected
Standard Accessories
One SpO2 adult finger probe
One charger
Specifications:
1. General
Monitoring Parameters: SpO2. PR. Pulse strength
Signal sockets: SpO2 socket. Adaptor socket
2. Display screen
Type: Red LED
Display area: 56mmX36mm
Size: 120mmX63mmX32mm
Weight: 300g(not include probes and adaptor)
3. Features
Audio and visual alarm: The speaker sounds the alarm and the parameter's measurement flashes on the screen.
Prompting: Icons of battery capacity, pulse sound switch and alarm sound switch.
Power saving: The monitor will automatic shut down when no monitoring for 3 minutes.
4. Electrical specifications
Working Voltage: D. C. 6.0V-D. C. 9.0V.
AC power adaptor
Input: AC 100 V-240V, 50/60Hz, 0.7A
Output: 8V D. C., 800mA
Internal battery
Type: 2Ahr/6V Ni/MH rechargeable battery
Run Time: 15-hour continuous operation with a new, fully charged battery (environment temperature is 2º C)
Recharge time: 10 hours
5. Environment
Temperature
Operation: 0 ~ 45 (º C)
Transportation and storage: -20 ~ 60 (º C)
Humidity
Operation: 15% - 95 %( noncondensing)
Transportation and storage: 10% - 95 % (noncondensing)
Altitude
Operation: 86 KPa ~106 KPa
Transportation and storage: 50KPa~106 KPa
6. Parameter Specifications
SpO2
Patient: Adult, child
Range: 35 - 99%
Resolution: 1 %
Accuracy: 2 %(70% - 99%),
PR
Range: 0~250bpm
Resolution: 1bpm
Accuracy: ± 2bpm
