| Quantity: | |
|---|---|
LS-35HD
Pressure Steam Sterilization Equipments
220V
Ultra High Temperature Alarm
Stainless Steel
Suzz20132570314
134oc
<=1oc
105~134oc
Hand Wheel Type of Quick-Open
Two Stainless Steel Sterilizing
CE, ISO
84192000
Pressure Steam
CE, ISO13485, ISO9001
Without LCD Display
Sterilization Information Recording and Printing
Type 3
0.22MPa
0.23 MPa
0~99min
Stainless Steel
Auto-Protection
everich
China
| Model technical data | LS-35HD | LS-50HD | LS-75HD | LS-100HD |
| Chamber volume | 35L(φ318×450)mm | 50L(φ340×550) mm | 75L(φ400×600) mm | 100L(φ440×650) mm |
| working pressure | 0.22MPa | 0.14 MPa | ||
| Working temperature | 134ºC | 126ºC | ||
| Max working pressure | 0.23 Mpa | 0.165 Mpa | ||
| Heat average | ≤±1ºC | |||
| Timer | 0~99min or 0~99hour59min | |||
| Adjustment of temperature | 105~134ºC | 105~126ºC | ||
| Power | 2.5Kw/AC220V.50Hz | 3Kw/AC220V.50Hz | 4.5Kw/AC220V.50Hz | |
| Overall dimension | 450×450×1010(mm) | 510×470×1130(mm) | 560×560×1120 (mm) | 540×560×1250 (mm) |
| Transport dimension | 570×550×1150(mm) | 590×590×1280(mm) | 650×630×1280(mm) | 680×630×1370(mm) |
| G.W/N.W | 72Kg/56Kg | 88Kg/ 68Kg | 100Kg/ 80Kg | 110Kg/ 85Kg |
| Model technical data | LS-35HD | LS-50HD | LS-75HD | LS-100HD |
| Chamber volume | 35L(φ318×450)mm | 50L(φ340×550) mm | 75L(φ400×600) mm | 100L(φ440×650) mm |
| working pressure | 0.22MPa | 0.14 MPa | ||
| Working temperature | 134ºC | 126ºC | ||
| Max working pressure | 0.23 Mpa | 0.165 Mpa | ||
| Heat average | ≤±1ºC | |||
| Timer | 0~99min or 0~99hour59min | |||
| Adjustment of temperature | 105~134ºC | 105~126ºC | ||
| Power | 2.5Kw/AC220V.50Hz | 3Kw/AC220V.50Hz | 4.5Kw/AC220V.50Hz | |
| Overall dimension | 450×450×1010(mm) | 510×470×1130(mm) | 560×560×1120 (mm) | 540×560×1250 (mm) |
| Transport dimension | 570×550×1150(mm) | 590×590×1280(mm) | 650×630×1280(mm) | 680×630×1370(mm) |
| G.W/N.W | 72Kg/56Kg | 88Kg/ 68Kg | 100Kg/ 80Kg | 110Kg/ 85Kg |
