Visible Spectrophotometer S23A B03.01004

Quantity:
  • S23A
  • CE, ISO13485
  • 340-950nm
  • <=1nm
  • +/_2% (Tube),+/0.5%(Cuvette)
  • 0.0-199.9%T
  • Serial Printer
  • CE
  • 90273000
  • Photometer
  • All People
  • +/-2.5nm
  • 12nm
  • 0.3%T
  • As232
  • everich
  • China
This model is designed for the purpose of education and general analysis in low cost. It can use tube (diameter: 10-16mm) or rectangular cuvette in simple department, high reliable and operate easily. It can be used for environmental protection, education etc. Qualitative analysis and quantitative analysis can be done.

Features:
1. The instrument has variable wavelength and four scales: Transmittance absorbency concentration and factor.
2. Using universal test tube or cuvette to make measure directly
3. The instrument is micro computerized and easy in operation
4. The 12nm spectral slit width provides the sensitivity required for almost any application
5. One solid-state silicon detector covers entire wavelength range. Eliminating the need to change detectors between different analysis.
6. It is easy to replace the unit of instrument specially the unit of the Pre-adjusted light source, and make it convenient to maintain.
7. Free adjusting for filter exchange

Specifications:
Wavelength range: 340-950nm
Wavelength accuracy: +/-2.5nm
Wavelength repeatability: ≤ 1nm
Spectral Slit width: 12nm
Photometry accuracy: +/-2% (tube), +/-0.5% (cuvette)
Photometry repeatability: 0.3%t
Photometry range: 0.0- 199.9%t
-0.3-2.999A
1-9999F
0-9999C
Interface: RS232
Print: Serial printer
Any printer (for software)
